Fittings technology for Schüco doors

In addition to Schüco door lock fittings, the different types of hinges (surface-mounted and barrel hinges, as well as concealed door hinges) and their durable fixing are another essential fittings component. Innovative approaches are dominated by a consistent, Schüco-specific design philosophy, faster fabrication and optimised fixing technology.


The tried-and-tested Schüco surface-mounted door hinges are particularly successful in projects with increased requirements for door systems to be more durable and more resistant to repeated opening and closing. As part of improving the range, this type of hinge has now been optimised technically in terms of design.


Features and benefits

  1. The outer contour, which is based on the design of the robust hinge, has been brought into line with contemporary design requirements.

  2. Innovative direct fixing using a special anchor screw for quicker fabrication.

  3. Continuous, solid hinge pin made of stainless steel makes the hinge highly robust.

  4. Enhanced adjustment and fixing options.

  5. Horizontal: ±2.5mm.

  6. Vertical: +3mm / -2mm.

  7. Gasket contact pressure: ±0.5mm.

  8. 2-part or 3-part design available.

  9. Able to bear loads up to 200kg leaf weight.

  10. Maintenance-free – no oiling or greasing.
