Schüco Window AWS 60 BS

Economical block construction for versatile applications.

Features and benefits

1. •Basic depth of outer frame 60 mm.


2. •Good thermal insulation due to two-part vent and glazing bead locating groove in the plastic component.


3. •Block window series with extremely narrow face widths from 67 mm and concealed vents.


4. •Transparent units due to proportionately narrow

   frames tolarge glass surfaces.


5. •No visible glazing beads.


6. •Ideally suited for use as insert units in facades.


7. •Profiles available in a variety of colours.


8. •Concealed drainage.


9. •Concealed Schüco AvanTec system fittings.


10. •Insert outer frame with adapter gasket to compensate for glazing thicknesses.


11. •Glass thickness of leaf 15 - 34 mm.


12. •Thermal insulation Uf = 2.1 - 2.8 W/m2K.


13. •Burglar resistance up to WK3 in accordance with DIN V ENV 1627.


14.
