Schüco Folding/ sliding system ASS 70 FD
Schüco folding/sliding system ASS 70 FD offers the benefits of a wide range of designs, quiet operation, perfect weather-tightness and high transparency.
Features and benefits
-
•Thermally insulated folding / sliding system.
-
•Narrow face widths from 120 mm (standard fold).
-
•Can also be used for balcony glazing.
-
•High degree of flexibility with large-scale projects due to the option for the customer to roll the profiles together.
-
•A turn / tilt ventilation window can be inserted in the folding vent on the outer frame side.
-
•Watertightness up to class 9A in accordance with DIN EN 12208.
-
•Maximum vent weight 100kg.
-
•Basic depth 70mm.
-
•Glass thicknesses 6 - 45mm.
-
•Vent size: maximum width 1200 mm, maximum height 3000mm.
ASS 70 FD
