Schüco Large Louvre Blades ALB
Due to their system technology, Schüco Large Louvre Blades ALB (Aluminium Louvre Blades) offer high quality with various implementation options. The wide range of louvre blades provides design freedom for individualised architecture. The horizonally or vertically arranged louvre blades can be mounted passively as well as installed as an active system
Linear drive
The maintenance-free linear drive allows even large blade profiles to be moved. Maximum blade span widths and a blade rotation of up to 110° are possible
Concealed drive
The large louvre blades with narrow face widths can be installed in particularly close proximity to the façade as the gearbox is being concealed within the drive mullion and the motor is compact. The maintenance-free AC motor can rotate the blades through a full 360°.
Features and benefits
-
•Hollow blades with widths of 105 - 470 mm and sheet metal blades with widths of 470, 580 and 690 mm mounted passively.
-
•Active large louvre blade systems consist of hollow blades with widths of 155 – 470 mm, glass or PV blades, needle blades or “hi-tech” blades.
-
•Active large louvre blade system with Schüco ProSol TF modules for flexible installation in front of windows and façades.
-
•Brise Soleil with Schüco ProSol TF modules for shading and to generate energy in a single unit.
